4 Way DMX Splitter/Booster
DD-4WM splitter is a 4-output DMX splitter with DMX pass-through supporting bi-directional communications for discovery, addressing and DMX Control. This unit takes the incoming DMX signal and splits the signal into 4 separate output channels. All 4 output ports have independent output driver to boost the DMX signal. Can be controlled from 512 to 4*512 channels. Isolated DMX Input/Outputs.
| Models | DD-4WM |
| Electrical | |
| Input Voltage | 12-24VDC |
| Power Consumption | 4.5W |
| Control | |
| Protocols | DMX512 Control |
| Power/Data Output | Eight 4-pin terminal sockets |
| DMX Inputs | 1 |
| DMX Thru Link | 1 |
| DMX Outputs | 4 |
| Physical | |
| Housing Material | Aluminum |
| Finish Color | Powder coating, Black |
| Connector | Compression screw terminals |
| Mounting | Surface Mounting |
| Dimensions (LXWxH) | 116.5*14.25*21.5mm |
| Weight | 145g |
| Environment | |
| Operating Temperature | -10℃ to +35℃ |
| Storage Temperature | -20℃ to +70℃ |
| Humidity | 0-90% non-condensing |
| IP Rating | Dry, Indoor IP20 |
| Certification and Safety | |
| Certification | CE |
| Warranty | 2Years Limited Warranty from the Date of ManufactureContact us if you need extended warranty |
